Automatic Weighing & Bagging Machine10-50kg Pneumatic Type
Item Code : 6403
Description:
To ensure precise and effective packaging, a pneumatic automatic weighing bagging machine employs compressed air to power a number of components for bag filling and weighing. The bag is pneumatically clamped, material is fed into a weighing hopper, and the material is subsequently discharged into the bag in accordance with predetermined weight targets.
Salient Features
Specifications
Salient Features
- Big Clear Digital LED Display digit height 25mm.
- Pneumatic bag holder.
- External weighing calibration.
- Model approval from weight and measurement, department of legal metrology, ministry of consumer affairs, govt. of India .
- Programmable net weight.
- Load cell based for better accuracy.
- Easy to operate.
- Gravity feeder.
Specifications
| Weighing Range | 10-50 kg |
| Accuracy | ± 0.5% |
| Display | 7 Segments, 7 Digit LED Display, Digit height 25 mm |
| Output Speed | 3 – 5 bags per min. (No. of bags per min depend upon the commodity being weighed, weight of bag and accuracy required). |
| Bag type | Open Mouth type. Stitchable jute and gunny bags HDPE wooven bags |
| Bag Holder | Pneumatic bag holder |
| Compressed air requirement | 6 Bar |
