Salient Features
Specifications
Salient Features
- Sample Basis: Changed from volume-based to weight-based (better accuracy across different grains).
- Pressure: Applied automatically using a motor instead of manual lever/handle.
- Higher Repeatability: Because both sample size and compression force are now standardized
Specifications
| Commodity Calibration | : Food Grains, Pulses, Oil Seeds, Vegetable Seeds, etc. |
| Moisture Measurement Range | : 3.5% to 40% |
| Consistency | : ± 0.2% |
| Principle of Measurement | : Resistance-based |
| Sample Type | : Weight-based (more accurate and consistent across different crop sizes) |
| Recommended Sample Weight | : As per commodity-specific calibration (typically 20g–50g) |
| Pressure Application | : Motorized pressure mechanism for consistent and repeatable compression |
| Motor Type | : DC geared motor with overload protection and automatic cut-off |
| Pressure Control | : Automatic with pre-set pressure profiles for various commodities |
| Temperature Compensation | : Automatic using PT-100 temperature sensor |
| Error Indications | : Under Range, Over Range, Pressure Error, Motor Overload |
| Display | : 2 x 16 character alphanumeric LCD |
| RS-232 Port | : Allows connection to printer or PC; prints Moisture %, Temperature, Commodity Name, Date & Time |
| Hot Keys | : 3 programmable hot keys for frequently used crops |
| Keypad | : Membrane type (9 keys) |
| Averaging Function | : User can average multiple readings with a single key press |
| Recall Function | : Last reading recall available |
| Data Logging | : Logs Moisture %, Temperature, Commodity Name & Code, Date & Time |
| Data Storage Capacity | : Up to 200 readings |
| Power Supply | : 230V ACÂ /Â 150 Watt aprox (During Compression) |
| Dimensions (L x B x H) Approx. | : 380 x 180 x 410mm (may vary depending on motor design) |
| Weight | Â : 22-24 kg Approx. |
